ZT 70cc UAV Engine
With a displacement of 61cc, this engine strikes a balance between power and agility, enabling UAVs to achieve impressive speeds and carry payloads with ease while maintaining stability and maneuverability. Its innovative design integrates cutting-edge features to optimize fuel consumption and reduce emissions, aligning with modern environmental standards and operational requirements. Whether utilized for surveillance, aerial photography, or recreational purposes, the ZT 70cc UAV Engine sets a new benchmark for drone propulsion systems, offering unparalleled performance and versatility in the rapidly evolving field of unmanned aerial operations.
CONTACT US

Overview

Product Description


1. Electronic fuel injection system, suitable for high-altitude flight.
2. Self-starting generator, two-in-one, output power 400W/600W.
3. The electrical part uses aviation plugs, which is more solid and reliable.

4. Adopt aviation aluminum materials and high-precision technology.

5. Beautiful appearance, high-precision, drop resistance, fatigue resistance, and strong power performance.

6. Applicable for civilian and military purposes, such as aerial photography, aerial survey, forest inspection, disaster rescue, etc.


Specifications


Performance

7HP/8500rpm

Idle Speed

1400rmp/minute

Static Thrust15.2kg/Altitude 100m

Static Thrust

13.5kg/Altitude 1800m

Recommended Propeller

22×10/23×8/23×10/24×8

Spark Plug Type

NGK CM6

Displacement

61cm³

Diameter×Stroke

36mm×30mm

Compression Ratio

7.6:1

Lubrication Ratio

30:1

Weight of Main Engine

1560g

Weight of Exhaust

200g

Weight of Ignition

190g

Ignition Voltage

4.8V-8.4V
